- Two versions available:
- Primary 115 VAC, 50/60 Hz. or
- Primary 117/234 VAC, 50/60 Hz.
- At 2,000 VAC and above, secondary leads are through rubber bushings.
- Units can be run full wave bridge or full wave C.T.
- V.A. is a CCS rating.
- Current ratings are CCS (continuous commercial service) and ICAS ratings (intermittent commercial or amateur service).
- Enclosed, 4 hole chassis mount.
- Minimum 6" long leads.
- Class A insulation (105°C).
- Hipot test at a minimum of twice secondary voltage.
- Conservative designs - CSA certified (#209651).
- Notes:
- VA rating specified is CCS (continuous commercial service).
- ICAS ratings (intermittent commercial or amateur service).
- 115 VAC only models - input black and black.
- Dual primary (117/230 VAC) models - 117 VAC input: connect blue to black and brown to white.
- 234 VAC input: connect brown to black - input is blue and white.
