106C | 106 Series | Hammond Manufacturing Transformers | KGA Enclosures Ltd
| Part No |
106C |
| GTIN UPC EAN |
623980180601 |
| Product Series |
106 Series |
| Typical Application | Input |
|---|
| Nominal Impedance (Ohms) Primary | 50000 |
|---|
| Nominal Impedance (Ohms) Secondary | 1,500 ct |
|---|
| Max. Primary D.C. ma. (*1) | 0 |
|---|
| D.C. Resistance (Ohms) +/- 15% Primary | 2400 |
|---|
| D.C. Resistance (Ohms) +/- 15% Secondary | 52 |
|---|
| Output Milliwatts (*2) | 10 |
|---|
| Insertion Loss db (*3) | 1 |
|---|
| Low Frequency Roll Off -1 db (Hz.) (*4) | 60 |
|---|
| Drawing Figure | 7 |
|---|
| RoHS Compliant |
Yes |
| REACH Compliant |
Yes |
