- Available in 24U and 42U mounting heights.
- Available in 42.74" overall depth.
- Surface-mounted doors allow full mounting depth utilization and include a locking swing handle.
- Included PDU cable trays for cable management and industry-standard vertical PDU installation.
- The top panel is easily removable for cable installation.
- Includes generous cable access with brushed cable entry.
- Includes fan venting compatible with FK Series fan kits.
- Includes three (4) 2U Rack panel cover panels.
- Ships with doors and rails fully assembled and ready for installation on-site. SIde panels come packaged inside the cabinet for on-site installation.
- The built-in joining kit speeds up the baying of multiple RB-DC cabinets within a row.
- Constructed in 16 gauge mild steel.
- Square hole mounting rails are constructed in 13 gauge mild steel, includes rack unit indicators, and are finished with a powder coat.
- Rails easy adjust in-depth in 1/4" increments.
- Tested to 2,200 lbs (1,000 kg) of equipment load. Rated for up to 300 lbs (136 kg) rolling cast load rating (including the weight of cabinet frame).
- Grounding studs bonded to the frame, side panels, and doors.
- Finished in textured black powder paint.
- Meets PCI DSS (Payment Card Industry Data Security Standard) compliance requirements.
- RoHS compliant.
- Steel frame with factory-installed leveling feet, recessed casters and grounding studs.
- Two (2) pairs of adjustable depth EIA-compliant square hole punched mounting rails.
- Starter pack of (50) M6 screws, cage nuts, and washers included.
- One (1) perforated front door (63% open area vented) with a locking swing handle.
- One (1) perforated split/barn rear door (63% open area vented) with locking swing handle.
- Two (2) pairs of solid, split, locking, and removable side panels.
- One (1) removable vented top panel.
- Two (2) PDU cable trays are mounted in the rear.
- The bottom of the cabinet is open.
