- Available in 24U, 36U, 40U and 45U mounting heights.
- Available in 23" overall width (19" mounting width).
- Available in 23.62" and 31.5" overall depths.
- C-channel struts provide cabinet strength, ease and flexibility to adjust mounting rails.
- Flush-mounted doors with quarter-turn lock.
- Solid side panels.
- One (1) interchangeable top panel.
- The cabinet frame is 14 gauge steel with 12 gauge steel reinforced corner brackets.
- Cabinet doors and side panels are constructed in 16 gauge steel.
- Drilled and 10-32 tapped combination 19" mounting rails are constructed in 12 gauge steel, include rack unit indicators, and are Zinc-plated to provide superior surface areas for equipment grounding.
- 1,500 lbs (680 kg) load rating.
- Grounding studs are provided on the frame, side panels, and doors. The front and rear studs on the cabinet frame conform to PET.
- Finished in textured RAL 9005 black or RAL 7035 light grey powder paint.
- TAA compliant for GSA schedule purchases.
- RoHS compliant.
- Manufactured in North America within an ISO 9001:2015 certified facility.
- All configurations include:
- Welded steel frame with factory-installed nylon leveling feet, grounding studs, and mounting points for optional casters.
- Two (2) pairs of adjustable depth EIA compliant 10-32 tapped flange mounting rails.
- Starter pack of SCREW1032-25 screws.
- Two (2) removable side panels (with 1/4 turn latches).
- C2RR Series Specific Components Include:
- One (1) solid locking door (Can be used as either front or rear door).
- One (1) solid top panel.
- C2RR "D" Series Specific Components Include (Replaced by C4RR).
- One (1) locking front window door.
- One (1) locking rear louvered door.
- One (1) vented top panel with four (4) 3.50" (89mm) diameter cable access holes with covers.
