- Built to meet the rugged requirements of commercial and industrial use.
- All metal housing - tough extruded aluminium case with a black powder paint coated steel cover.
- Heavy duty NEMA 5-15R receptacles.
- Mounting feet (with keyhole slots) allow temporary work station mounting if desired.
- On/Off switch is rocker type with pilot light (on units with on/off switch). A red pilot light is used to indicate power on (on units with no switch).
- Heavy duty 14-gauge wire cord - 14/3 SJT type for extreme temperature ranges and integral moulded plug.
- Plug types available are NEMA 5-15P straight blade or NEMA L5-15P locking type.
- Includes 15 amp, 1250 volt resettable circuit breaker to prevent accidental line overload.
- Includes our surge module:
- Max energy (joules) is 1080 J.
- 25,000 amp rated MOV's for a total of 75,000 amps of single pulse transient current.
- Voltage protection rating (Vpr) of 500 volts, in all 4 modes (L-N, L-G, N-G).
- Nominal discharge current (In) of 5kA.
- Voltage suppression at the outlet guards against transients from equipment on the outlet strip.
- Green indicator light confirms surge module is active.
- Internal protection will disconnect the surge module at the end of its useful life (and extinguish the green light) but will maintain power to the load, now unprotected.
- cULus listed to UL 1449 and C22.2 #269.3-17, for surge protective devices - type 3.
- cULus listed to UL 1363 and C22.2 #308-18, for relocatable power taps and multi outlet assemblies.
- TAA-compliant for GSA schedule purchases.
- RoHS compliant.
- Manufactured in North America.
- For our non-surge protected versions, see our 1584 Series.
KGA Enclosures Ltd is a fully authorised distributor of the 1584-S Series from Hammond Manufacturing Power Distribution. We also stock the entire Hammond Manufacturing Power Distribution range at great competitive pricing and with full customisation options on all applicable products.
Please remember to always use approved distributors like KGA Enclosures Ltd as some companies sell knock-offs and copies, so using approved suppliers assures you receive a genuine product.
To purchase a product, request a quote/lead time and for all other general enquires, please contact us. We aim to respond promptly to all enquires. Payment options include Bank Transfer, PayPal and Credit/Debit cards. Unfortunately, we do not accept cash and cheques.
